product
PXI 50 X DPST Ruthenium Reed Relays
40-141-022
The 40-140A/141/143 range of high density switching modules are available in Normally Open (SPST & DPST) and changeover (SPDT) configurations. Connections are made via a front panel 200 pin female connector.
-
product
PXI Solid State Switch Module, 6xSPST, 30 A, Hardware Interlock
40-183B-011-HI
The 40-183B-011-HI has 6 high current SPST switches with hardware interlock in two PXI chassis slots. Each SPST switch uses a fully isolated solid state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation.
-
product
Solid State Relays for AC Power Switching Applications Requiring High-Rel and High Safety
Series KA/LA
Series KA/LA solid-state relays are designed for use in AC power switching applications where safety and reliability are primary concerns. They are ideal for resistive and reactive loads with power factors as low as 0.2. Inverse parallel SCRs are configured for zero-voltage turn on. The relays are available with thermal protection and thermal trip status.MSL 1 Available options include:KA58HF 2Arms, 250Vrms Load; 3.8-32Vdc bias voltage, 250µA CMOS Control; includes thermal protection & thermal trip statusLA00HL 2Arms (7.5Arms with heat sink), 250Vrms Load; 3.8-32Vdc bias voltage, 250µA CMOS Control; LA58HL 2Arms (7.5Arms with heat sink), 250Vrms Load; 3.8-32Vdc bias voltage, 250µA CMOS Control; includes thermal protection & thermal trip status
-
product
NI-9485 , 8-Channel, SSR Relay, 60 VDC/30 Vrms, 750 mA C Series Relay Output Module
779600-01
The NI-9485 allows for direct connection to a wide array of industrial devices such as motors, actuators, and DC devices. Each channel provides access to a solid state relay (SSR) for switching voltages up to 60 VDC/30 Vrms with switching current up to 750 mA per channel or up to 1.2 A on four channels. Each channel also features channel-to-channel isolation.
-
product
Digital I/O Products
Digital I/O series products provide computer monitoring of digital input and digital output signals for control of industrial devices through solid state relays.
-
product
PXI Solid State Multiplexer Module, Dual 3-Channel, 10 A, Hardware Interlock
40-666B-011-HI
The 40-666B-011-HI is a dual 3-channel 10A MUX with hardware interlock and is part of our range of high current multiplexers occupying two slots of PXI chassis. Each multiplexer switch uses a fully isolated solid state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation.
-
product
IndustryPack Module
IP-OptoISO-16
The IP-OptoISO-16 is an IndustryPack Module with 16 optically controlled FETs [switch]. Each FET acts as a single pole normally open photovoltaic relay. The solid state approach has several advantages including bounce free operation, low on resistance, long life, fast switching, and higher reliability when compared to relays.
-
product
NI-9485, 8-Channel, SSR Relay, 60 VDC/30 Vrms, 750 mA C Series Relay Output Module
779600-02
The NI-9485 allows for direct connection to a wide array of industrial devices such as motors, actuators, and DC devices. Each channel provides access to a solid state relay (SSR) for switching voltages up to 60 VDC/30 Vrms with switching current up to 750 mA per channel or up to 1.2 A on four channels. Each channel also features channel-to-channel isolation.
-
product
PCI Multifunction I/O
626
6 versatile 24-bit counters for encoders/timers with interrupt generation Fail-safe Digital I/O E-stop Relay Battery backup of counters Four 14-bit D/A outputs, 20 Khz update rate Sixteen 16-bit differential A/D inputs, 15 kHz rate Watchdog timer may be used to reset PCI bus 48 bi-directional digital signals for solid state relay boards, 40 with edge detection and interrupts
-
product
Low On-state Resistance
Is a low output capacitance solid state relay containing a GaAs LED on the light emitting side (input side) and MOS FETs on the output side. A small flat-lead package has been provided which realizes a reduction in mounting area of about 50% compared withthe PS78xx series. It is suitable for high-frequency signal control, due to its low C × R, low output capacitance, and low off-state leakage current.
-
product
Solid State Relays with Low ON Resistance
Series CD
The CD series Solid-state Relay utilizes the latest technology to provide a low ON resistance. The control circuit is buffered to enable the relay to be driven directly from standard CMOS or open collector TTL logic circuits. Available options include short circuit protection and current overload protection or a status output line.MSL 1CD relays are controlled by 3.8-6VdcC = Through-hole mount SC = Surface mountAvailable options include:CD00CF 2A, 60Vdc LoadSCD00CF 2A, 60Vdc LoadCD01CF 2A, 60Vdc Load; control statusSCD01CF 2A, 60Vdc Load; control statusCD20CD 1A, 60Vdc Load; short-circuit protectionSCD20CD 1A, 60Vdc Load; short circuit protectionCD21CD 1A, 60Vdc Load; short-circuit protection & control statusSCD21CD 1A, 60Vdc Load; short circuit protection & control status
-
product
Solid State Relays
As well as being slim and thus saving panel space, The relays are very strong, have a large contact area and non-bendable pins. Connection to a PLC is easy and achieved faultlessly in a few seconds via click connectors. In addition, power switching in G3RV relays with DC outputs is managed by a MOSFET in the output, which has ideal heat dissipation characteristics.
-
product
Switch PXI Solid-State Switch Module, 6xSPST, 25 A, 100 V
40-184A-001
The 40-184A-001 has 6-off high current SPST switches in two PXI slots and is part of our range of high power solid state switching solutions. Each SPST switch uses a fully isolated solid-state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation.
-
product
PXI Solid State Multiplexer Module, Dual 3-Channel, 10 A
40-666B-011
The 40-666B-011 is a dual 3-channel 10A MUX and is part of our range of high current multiplexers occupying two slots of PXI chassis. Each multiplexer switch uses a fully isolated solid state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation. Each multiplexer channel can support 10A of continuous current and switch up to 200V signals. The switches can sustain inrush currents in excess of 50A. AC or DC signals can be switched since the switch is polarity insensitive.
-
product
PXI Solid State Very High Density Matrix
40-501-001
The 40-501 is a very high density matrix using solid state switching configured as a 64x4 1-pole matrix in a single slot 3U PXI module. It is ideal for applications requiring fast operation and a long service life with frequent switch operations at high voltages. Since the design is based on solid state relays the matrix has no wear out mechanism.
-
product
Load Cell Transmitter
MODEL SST-HV
The SST-HV is a Plug & Play Smart TEDS IEEE 1451.4 compliant Transmitter. Just plug in a TEDS compatible Load Cell or Torque Sensor and the SST-HV will automatically self-calibrate. When used with a non-TEDS Load Cell or Torque Sensor, the SST-LV Transmitter is easily programmed using a PC with an RS232 port and Instrument Setup (IS) software, which provides a graphical user interface. The SST-HV may be powered from 95-240 Vac ±10%. The SST-HV has an Isolated transducer excitation output that is selectable between 5Vdc or 10Vdc. There are Dual solid state relays and an Isolated 4-20 mA, 0-20 mA or 0-10V analog output. There are three Isolated serial data transmitter output ( RS232 , Half-duplex RS485, full-duplex RS485 ) and three serial protocols that are software selectable (Modbus RTU, Modbus ASCII and Custom ASCII). Isolation to 250V rms is provided for power, signal input, analog output, relay outputs, and communications. Isolation adds safety and avoids possible ground loops. The transducer excitation output is isolated to 50V from signal ground.
-
product
PXI Solid State Multiplexer, 5 Amp, Dual 24-Channel, 1-Pole
40-652A-002
The 40-652-002 is a dual 24-channel, 1-pole MUX and is part of our range of multiplexers uses solid state relays with high tolerance to surge currents and hot switching events. These multiplexers provides an isolation relay in the common to minimize capacitive loading when expanding the multiplexer across multiple modules. The 40-652 can sustain 30A for 300µs on hot or cold switching.
-
product
PXI Solid-State Switch Module, 3xSPST, 25 A, 100 V
40-184A-002
The 40-184A-002 has 3-off high current SPST switches in one PXI slot and is part of our range of high power solid state switching solutions. Each SPST switch uses a fully isolated solid-state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation.
-
product
PXI Solid-State Matrix Module, 6x2, 10 A, Hardware Interlock
40-553A-011-HI
The 40-553A-011-HI is a high current 6x2 matrix with hardware interlock occupying two slots of PXI chassis. Each matrix crosspoint uses a fully isolated solid state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation.
-
product
Solid State Relays for Switching Heavy Loads with Physically Small 6-pin DIP Package
Series C60
Series C60 solid-state relays use an advanced design capable of switching very heavy loads in a physically small 6-pin mini-DIP package. These relays have a power FET output that ensures low ON resistance, no offset voltage and low leakage current. They are versatile and can be used to switch AC, bidirectional or DC loads.MSL 6C = Through-hole mount SC = Surface mountAvailable options include:C60-10 2.5Adc, 60Vdc DC-Load; ±1.25Adc, ±60Vdc AC-Load; 10-50mAdc ControlSC60-10 2.5Adc, 60Vdc DC-Load; ±1.25Adc, ±60Vdc AC-Load; 10-50mAdc ControlC60-20 1.5Adc, 100Vdc DC-Load; ±0.75Adc, ±100Vdc AC-Load; 10-50mAdc ControlSC60-20 1.5Adc, 100Vdc DC-Load; ±0.75Adc, ±100Vdc AC-Load; 10-50mAdc ControlC60-30 1Adc, 200Vdc DC-Load; ±0.5Adc, ±200Vdc AC-Load; 10-50mAdc ControlSC60-30 1Adc, 200Vdc DC-Load; ±0.5Adc, ±200Vdc AC-Load; 10-50mAdc ControlC60-40 0.5Adc, 400Vdc DC-Load; ±0.25Adc, ±400Vdc AC-Load; 10-50mAdc ControlSC60-40 0.5Adc, 400Vdc DC-Load; ±0.25Adc, ±400Vdc AC-Load; 10-50mAdc Control
-
product
PXI Single 6-Channel 30A Solid State MUX
40-667-012
The 40-667 is a high current multiplexer available in dual 3-channel or single 6-channel configurations occupying two slots of PXI chassis. Each multiplexer switch uses a fully isolated solid state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation. Each multiplexer channel can support 30A of continuous current and switch up to 40V signals. The switches can sustain inrush currents in excess of 120A. AC or DC signals can be switched since the switch is polarity insensitive.
-
product
PXI 10A Fault Insertion Switch 6-chan 2-bus
40-192-012
This PXI fault insertion switch uses solid state switching elements and is capable of switching current up to 10A. It is designed to be able to insert three different fault conditions between the test fixture and the equipment under test: Open-Circuit. Short-Circuit between UUT connections. Short-Circuit to external signals. Through relays on each channel enable signals to the UUT to be set open-circuit. Fault Insertion Buses allow any channel to be shorted to any other channel and also enable any channel to be connected to an external signal such as Power, Ignition or Ground to simulate fault conditions. The module is supplied with 2 fault buses.
-
product
Solid State Relays for Switching Heavy Loads with Physically Small 6-pin DIP Package
Part No. ZD24CC
Series ZD24CC solid-state relays use an advanced design capable of switching heavy loads in a physically small 6-pin DIP package These relays have a power FET output that ensures low ON resistance and low leakage current. Optical isolation ensures complete protection of signal lines, power and ground bus and control circuits from switching noise and EMI.MSL 6Available options include:ZD24CC 0.5A, 80Vdc Load; 8-20mAdc Control; through hole mountedSZD24CC 0.5A, 80Vdc Load; 8-20mAdc Control; surface mounted
-
product
High-Power PXI Switch Matrix Modules
These high-power PXI switch matrix modules provide higher current and power ratings than the high-density switch versions. These modules are designed for the switching of AC or DC loads or for controlling large relay or solenoid systems. The solid state relay matrices occupy two PXI slots and are suitable for automotive and aerospace test applications.
-
product
Relay And Protection Testing
As the first protection relay test set manufacturer in China, PONOVO has been always offering reliable protection relay testing equipment for customer for more than 20 years. More than 20,000 relay test kits has been supplied to users in China and other countries, including 6-phase, 3-phase, single phase relay test sets, capable of testing all kinds of protection relays, from electromagnetic relays, solid state, numerical, microcomputer relays and digital relays based on IEC61850 as well as other testings, such as, energy meter, transducer, etc. With various models with different specifications, users can definitely choose the model suitable for their testings.
-
product
Relays
Sensata is a global leader in relay technology and offer a wide range of high-performance solid state relays, high voltage relays and reed relays. Our relays are designed to work in a variety of markets, including automotive, telecommunication, military and aerospace, medical, instrumentation, and alternative energy.
-
product
PXI Solid State Multiplexer Module, Single 6-Channel, 10 A
40-666B-012
The 40-666B-012 is a single 6-channel 10A MUX and is part of our range of high current multiplexers occupying two slots of PXI chassis. Each multiplexer switch uses a fully isolated solid state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation. Each multiplexer channel can support 10A of continuous current and switch up to 200V signals. The switches can sustain inrush currents in excess of 50A. AC or DC signals can be switched since the switch is polarity insensitive.
-
product
PXI 3-Channel 10A Solid State SPST Switch
40-182-012
The 40-182-012 has 3 off high current SPST switches in one PXI slot and is part of our range of high power solid state switching solutions. Each SPST switch uses a fully isolated solid state relay which has been designed to offer fast operation under hot switching conditions and high inrush current with no operational life degradation. Each SPST switch can support 10A of continuous current and switch up to 200V signals. The switch can sustain inrush currents in excess of 50A. AC or DC signals can be switched since the switch is polarity insensitive.
-
product
Voltage Protection
Are solid state voltage sensing relays with electromechanical output contacts built in a fully draw out case format. Designed for application on AC & DC voltage systems, these relays are ideally suited to monitor power supply voltage levels wherever high accuracy and reliable, maintenance free operation is essential. All power to operate the relays is derived from the sensed input voltage therefore an auxiliary supply is not required.
-
product
Solid State Relay for AC Power Switching Applications
Part No. 682
The 682 is a state-of-the-art solid-state relay designed for use in AC power switching applications. Back-to-back SCRs are configured for zero-voltage turn-on and can handle current surges up to 8A. The patented circuit design assures the lowest possible EMI by virtually eliminating commutation spikes while maintaining excellent noise immunity.MSL 1 Available options include:682-1 2A, 250Vrms Load; 3.8-32Vdc Control
-
product
Solid State Relay
SSR
Series SSR Solid State Relays amplify the current handling capability of a variety of sensors for controlling higher power loads. The relays are compact, totally encapsulated and impervious to shock or vibration.
